Homogenizer Seals

Any specification can be supplied on quick delivery at very competitive prices.

Homogenizer seals are crevice-free hygienic seals for use with higher pressure applications.
The popular model is a button design but a fishtail model is also available.

Typical application : Dairy industry

Seal & Diaphragm Material : AISI 316L stainless steel
Mounting Options : Block
Fill Fluid : FDA approved non-toxic glycerine (standard) or others to suit application
Instrument Connection : 1/2" BSP (standard) others to special order
Normal Operating Range : 60 - 1000 bar maximum

Options
Cooling tower (for medium fluid temperature over 100°C)
Capillary tube for remote instrument reading
