Need a specific configuration? If you can’t find the exact specifications or components you require, please get in touch with our team - we are here to help.
40mm – Industrial Pressure Gauge – Dry, Bottom Connection – Accuracy ±2.5%
Price range: £7.95 through £13.45
40mm industrial dry pressure gauge with bottom brass connection, black enameled steel case and ±2.5% accuracy, ideal for pneumatic and air pressure measurement.
Industrial 40mm Dry Pressure Gauge with Bottom Connection
This 40mm industrial pressure gauge is designed for reliable measurement of pneumatic and air pressure in general purpose applications. Its robust black enameled steel case and brass wetted parts ensure durability and corrosion resistance, making it suitable for a variety of industrial environments.
Key Features
- Compact 40mm diameter for easy installation in tight spaces
- Durable black enameled steel case with a clear, push-fit acrylic window
- Brass wetted parts provide good corrosion resistance for pneumatic and air applications
- Bottom connection for straightforward direct mounting
- Accuracy of ±2.5% full scale for dependable pressure readings
- Suitable for non-corrosive fluids and gases up to 25 bar (excluding oxygen and acetylene)
| Weight | 0.06 kg |
|---|---|
| Range | 0/30 psi and 0/2 bar 0/60 psi and 0/4 bar 0/100 psi and 0/7 bar 0/160 psi and 0/11 bar |
| Thread | 1/8" BSPT (tapered) 1/4" BSP (parallel) 1/4" NPT (tapered) 1/4" BSPT (tapered) |
| Connection | |
| Diameter | |
| Case Material | |
| Accuracy | |
| Wetted Material |
