40mm – Glycerine Filled Pressure Gauge – Bottom Connection – Accuracy ±2.5%
Price range: £32.95 through £43.45
40mm industrial pressure gauge with bottom connection, stainless steel case, brass wetted parts and ±2.5% accuracy, ideal for reliable pressure measurement in non-corrosive fluids and gases.
Industrial 40mm Glycerine Filled Pressure Gauge with Bottom Connection
This robust 40mm pressure gauge is designed for reliable measurement of fluid liquids and non-oxidising gases in industrial environments. Its stainless steel case and dry fillable design make it suitable for applications where vibration or oscillation is minimal, providing clear and accurate readings.
Key Features
- Compact 40mm diameter ideal for tight spaces and panel mounting
- Durable stainless steel case with crimped bezel and clear polycarbonate window for corrosion resistance and impact protection
- Brass wetted parts compatible with non-corrosive fluids and gases up to 25 bar
- Bottom connection for easy installation in standard piping systems
- Accuracy of ±2.5% full scale for dependable pressure readings
- Suitable for measuring pressure in liquids and non-oxidising gases such as oxygen and acetylene
| Weight | 0.06 kg |
|---|---|
| Range | -30/0 in Hg and -1/0 bar -30/0 in Hg vacuum to 0/+30 psi pressure 0/15 psi and 0/1 bar 0/30 psi and 0/2 bar 0/60 psi and 0/4 bar 0/100 psi and 0/7 bar 0/160 psi and 0/11 bar 0/200 psi and 0/14 bar 0/300 psi and 0/21 bar 0/400 psi and 0/28 bar 0/600 psi and 0/41 bar 0/1000 psi and 0/70 bar 0/1500 psi and 0/103 bar 0/2000 psi and 0/138 bar 0/2500 psi and 0/172 bar 0/3000 psi and 0/207 bar 0/4000 psi and 0/275 bar |
| Thread | 1/8" BSP (parallel) 1/8" BSPT (tapered) 1/4" BSP (parallel) 1/4" NPT (tapered) 1/4" BSPT (tapered) |
| Mounting | |
| Connection | |
| Diameter | |
| Case Material | |
| Glycerin Filled | |
| Accuracy | |
| Wetted Material |
